Tank Pool 2 1/2" PT Thread Liquid Level Sensor Stainless Steel Floating Ball

Key Features

• Product Name Water Flow Sensor; Model SEN-HZ06FA; Flow Range 0.15-1.5L/min; Working Voltage & Current DC4.5V-18V, 10mA
• Rated Voltage DC5V; Pulse Duty Factor 50 %; High Level of Pulse Output >4.5V; Low Level of Pulse Output <0.5V
• 0.8Mpa; Insulation Performance(Min.) 100M ohm; Connector Type 3PinJST Connector; Main Material POM
• Inside Magnet Quantity 2; Total Size 63 x 40x 23mm / 2.5" x 1.6" x 0.91"(L*W*T); Thread Diameter G1/4; Outlet Outside Diameter 6mm
• Cable Length 32cm / 12.6"; Body Color White; Weight 28g; Package Content 1 x Water Flow Sensor

Product Description

Description

100% brand new, high quality and high Precision Portable size and light weight, easy to install With stainless steel ball inside of the impeller, wear-proof Up and down structure stress applied for the seal ring, avoid to leak Imported Hall element, adopt pouring sealant encapsulation to avoid to leak and age Mainly used for water heater, boiler, water dispensers, coffee machines, steam equipment, campus card sale of water system, water treatment equipment, cooling systems, mechanical equipment, instrumentation, pharmaceutical (system economy) equipment, etc.

Note

Avoid strong impact and chemical erosion; Forbid to throw or collision; Install vertically, angle of inclination should not be exceeded 5 degree Medium temperature should not be exceeded 120 Celsius
