SM/MM MPO Fiber Optic Connector, Low Loss Quick Optical Adapter for OM4 MPO/MTP Red 44x17x10mm

Key Features

• [PARAMETER] fit for MPO/MTP; Multi-mode/Single-mode; Insertion Loss Typical Value ≤0.20dB.
• [CONNECTION] One end of the adapter connects to a male connector,and the other connects to a female connector.
• [CORE or CABLE] The adapter applies to the core of 4 - 24 fiber connection.
• [TESTED WAVELENGTH] 1310nm, 1550nm, 850nm, 1300nm.
• [EASY to INSTALL] The up-down key slot makes the installation easy.

Product Description

Description

1.One end of the adapter connects to a male connector, and the other connects to a female connector.2.The fiber optical quick connector applies to both single mode(SM) and multi-mode(MM).3.The adapter applies to the core of 4 - 24 fiber connection.4.The method to fix the connectors is up-down key slot.5.Low insertion loss.Specification:MPO: Multi-fiber Push OnMaterial: PCFiber Mode: Single and MultimodeOperation Temperature: -20 to +75°CTested Wavelength: 1310nm, 1550nm, 850nm, 1300nmInsertion Loss Typical Value: ≤0.20dBInsertion Loss Maximum Value: ≤0.30dBColor: RedTotal Size: 44x17x10mm / 1.73x0.67x0.39-inchPackage Included: 1 pcs x Fiber Optic Connector
