Self Tapping Threaded Inserts M5 M8x10mm 45# Carbon Steel Repairing Nuts 40pcs

Key Features

• Product Name Threaded Inserts; Finish Zinc Plating; Color Gold Tone; Inner Thread Size M5 x 0.8((Dia.x Pitch); Outer Thread Size M8 x 1(Dia.x Pitch); Length 10mm / 0.39"
• Min. Drilling Size 2.3 x 4mm / 0.09"x0.16"(wide*depth); Reference Drilling Diameter 7.1-7.2mm(Plastic), 7.3-7.5mm(Aluminum Alloy), 7.5-7.6mm(Cast Iron)
• Material 45# Carbon steel material, suitable for aluminum alloy, copper alloy, plastic and other substrates with low engineering strength. Strong resistance to vibration, can prevent loosening.
• Advantages With self-tapping capability, the base material does not need to be tapped in advance. It has a repairing effect on the female thread of the broken tooth, can continue to use the same screws by using the self-tapping screw sleeve.
• Application Installation easily, and only one assembly tool is required. It is widely used in household appliances, the shipping industry, construction machinery, electronic products, modular furniture and other places.

Product Description

Description

1. Material: 45# Carbon Steel material, suitable for aluminum alloy, copper alloy, plastic and other substrates with low engineering strength. Strong resistance to vibration, can prevent loosening.2. Advantages: With self-tapping capability, the base material does not need to be tapped in advance. It has a repairing effect on the female thread of the broken tooth, can continue to use the same screws by using the self-tapping screw sleeve.3. Application: Installation easily, and only one assembly tool is required. It is widely used in household appliances, the shipping industry, construction machinery, electronic products, modular furniture and other places.Specification:Product Name: Threaded InsertsMaterial: 45# Carbon SteelFinish: Zinc PlatingColor: Gold ToneInner Thread Size: M5 x 0.8((Dia.x Pitch)Outer Thread Size: M8 x 1(Dia.x Pitch)Length: 10mm / 0.39"Min. Drilling Size: 2.3 x 4mm / 0.09"x0.16"(wide*depth)Reference Drilling Diameter: 7.1-7.2mm(Plastic), 7.3-7.5mm(Aluminum Alloy), 7.5-7.6mm(Cast Iron)

Package Content

40 x Threaded Inserts
