LinkMejor DSO152 Handheld Oscilloscope 200kHz Bandwidth, 2.5MS/s Sampling Rate

DSO152 —— 200K Bandwidth
Channel：1
Sampling rate：2.5MS/s
Vertical sensitivity：10mV/Div-20V/Div(Progress according to the 1-2-5 way)
Time base range：10μs/Div-50s/Div(Progress according to the 1-2-5 way)
Voltage range：X1: ±40V (Vpp:80V) ; X10: ±400V (Vpp :800V)
Trigger method：Auto/Normal/Single
Coupling method：AC/DC
Display：2.8 inches/PPI:320*240
USB charging：5V/1A
Lithium battery capacity：1000mAh
Square wave calibration：Frequency: 1K Duty cycle: 50%
Size：99x68.3x19.5mm
Weight：100g

Accessories List
DSO 152 Host device *1
P6100 High Voltage Probe *1
Adapter *1
Alligator clip probe *1
Charging cable *1
Lanyard *1
User Manual *1
Packaging color box *1
