G1/4 180 Degree Hall Effect Water Flow Sensor 0.2-2.5 L/Minutes 0.8 mPa

Key Features

• Product name water flow sensor, model sen-hz06w, Type straight Type, flow range 0.2-2.5L/min
• Working Voltage & current dc3v-18v, 10mA, rated Voltage DC5V, pulse duty Factor 50 percent high level of pulse output >4.5V
• Low level of pulse output <0.5V, max pressure 0.8MPa, insulation performance.) 100mω, Connector Type 3Pinjst Connector
• Main material POM, total Size 60 x 40x 22 mm / 2.4" x 1.6" x 0.87"(L*w*t), outlet=inlet outer diameter G1/4, cable Length 33 cm / 13"
• Body color white, weight 26G, package content 1 x water flow sensor

Product Description

Mainly used for water heater, boiler, water dispensers, coffee machines, steam equipment, Campus card sale of water system, water treatment equipment, cooling systems, mechanical equipment, instrumentation, pharmaceutical (system economy) equipment, etc. 180 degree straight type G1/4 male thread outlet and Inlet ports. Water Inlet and Outlet the gate with the arrow Sign.
