Deep Groove Ball Bearing 6304RS Single Sealed, 20 x 52 x 15mm Chrome Steel Bearings,2pcs

Key Features

• Size 6304RS (Inner Dia.=20mm, Outer Dia.=52mm, Thickness=15mm)
• Sealed on single sides of the bearing for easy lubrication and maintenance while protecting from dirt. Ideal for vertical installation
• Chromium Steel long-life bearings, smooth and low noise
• ABEC Tolerance 1 (P0), Z2 Noise Level for most general use
• Same As 6304RS / 160304. Pre-Lubricated, Easy to maintain

Product Description

NOTE：Please refer to the picture and select right type of bearings before your order (Sealed or Shield on BOTH or SINGLE side of the bearing). Suffix on the bearing just for differentiating between Sealed and Shield type of bearing. It would not affect the use of our product.

Description

Deep Groove Ball Bearings are one of the most widely used rolling bearings. They are used to accommodate radial and axial loads in both directions.Suitable for all kinds of industrial equipment, micro motor, small rotary motor, office equipment and so on.With small friction and high-limit speed, Deep Groove Ball Bearings are cost-effective and require little maintenance.Chromium Steel (GCr15) made with heat treating, provides high and uniform hardness, good wear resistance.Single-row, pre-lubricated, normal accuracy.Selection Guide:Shields (Designation Suffix Z/ZZ) - High speed. Protect from dirt and debris.Sealed (Designation SuffixRS/2RS) - Made of sheet steel reinforced nitrile butadiene rubber (oil- and liquid-resistant). Lower limit speed than Shield Bearings.Specification:Model: 6304RSSealed Type: Single SealedCage Material: Stamping SteelInner Diameter (d): 20mmOuter Diameter (D): 52mmThickness (B): 15mmDynamic Load Rating (Cr): 15.8kNStatic Load Rating (Cor): 7.88kNAccuracy Class: P0 (ABEC1)Number of Pack: 2 PcsWeight: 274g

Specifications
