AXK0819+2AS, F8-16M Needle Roller Thrust Bearings with Washers 5pcs

Key Features

• Size - Bearing Model AXK0819 (I.D.=8mm, O.D.=19mm, Thickness=2mm), Washer Model AS0819; F8-16M (Bore Diameter=8mm, Outer Diameter=16mm, Thickness=5mm)
• Material - Chromium steel rollers for heat tolerance and durability under heavy loads; Steel cage guides and evenly spaced rollers for reduced friction, vibration, and noise
• Features - Needle Roller Thrust Bearings can accommodate axial loads in one direction only
• Washers - Combined with 2 washers for applications where adjacent machine components cannot serve as raceways
• Package Content 1 x AXK0819+2AS, 4pcs x F8-16M

Product Description

Description

These Needle Roller Thrust Bearings provide a high degree of stiffness within a minimum space. It has a smaller cross-section than a standard thrust bearing for use in restricted spaces.These bearings accommodate heavy peak loads due to the small diameter deviation of the rollers within one assembly.Thrust Bearings can be combined with washers in applications where adjacent components cannot serve as raceways.Made of hardened spring steel, both faces of the washers are polished and can be used as raceways.Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment, robotics, elevators, rolling mills, ship rudder shafts, and aggregate crushers, among others.Specification:Bearing No.: AXK0819+2AS, F8-16MNeedle Roller Material: Chromium Steel (GCr15)Cage Material: ST13 Steel, BrassBore Diameter: 8mm, 8mmOutside Diameter: 19mm, 16mmBearing Thickness: 2mm, 3mmWasher Thickness: 1mm, 1mmTotal Thickness: 4mm, 5mm

Package Content

1 x AXK0819+2AS4 x F8-16M
