Aviation Connector, 36mm 50P 5A YP36-50 Waterproof Male Wire Panel Power Chassis Metal Fittings Connector Aviation Silver Tone

Key Features

• Mounting Hole Distance 33mm/1.3"; Terminal Number 50 Terminals; Rated Current 5A;Total Size 3.03" x 1.77"; The Wire Hole Diameter 27mm/1.06"; Terminal Diameter 2mm/0.08"
• Contact Material Brass with silver plating; Net Weight 141g; Opening size 36mm/1.41"
• Color Silver Tone, Black; Qualification CE; Model YP36-50
• Contact Resistance <0.01ohm; Insulation Resistance >500Mohm; Temperature Range -25~80C
• The Aviation connector is widely used in signal and electronic connector of aviation, space light, post and telecommunications, computer, navigation and various kinds of instruments, CNC machine etc

Product Description

Mounting Hole Distance: 33mm/1.3"; Terminal Number: 50 Terminals; Rated Current: 5A;Total Size: 3.03" x 1.77"; The Wire Hole Diameter: 27mm/1.06"; Terminal Diameter: 2mm/0.08" Contact Material: Brass with silver plating; Net Weight: 141g; Opening size: 36mm/1.41" Color: Silver Tone, Black; Qualification: CE; Model: YP36-50 Contact Resistance: 500Mohm; Temperature Range: -25~80C The Aviation connector is widely used in signal and electronic connector of aviation, space light, post and telecommunications, computer, navigation and various kinds of instruments, CNC machine etc ›

Specifications
