8mm Hall Effect Liquid Water Flow Sensor Switch Flow Counter Meter 1.2-12L/min SEN-CL08C

Key Features

• Stable, high temperature, low water pressure start.
• Brass material, small size, easy to install.Hall element is imported, water-proof design to prevent water ingress,The inside of the impeller is inlaid with a stainless steel shaft and is always wear-resistant.
• The water flow sensor is applied for water heater, and can be used as flow switch.
• All materials are in line with SGS testing standards.
• Flow Range 1.2-12L/min; Maximum Water Pressure 1.75 Mpa

Product Description

Descriptions

1.Suitable for 8mm inner diameter hose.2.Water Flow Switch adopts a Magnetic Reed Switch and a movable magnet which is fixed inside the water pipe. When water flows in the pipe, the magnet will detect the water flow and make the reed switch close or open.3.Mainly used for water heater, boiler, coffee machines, hot card machines, steam equipment, water system, selling self-help water systems, water treatment equipment, cooling systems, mechanical equipment, instrumentation.

Specifications

Product Name: Water Flow SensorMaterial: Brass(Shell)Liquid Temperature: Not More Than 60CFlow Range: 1.2-12L/minConnector Size: 8mmMax Switch Voltage: DC250VMax Contact Rating: 70WMax Current: 0.3AMaximum Water Pressure: 1.75MPaCable Length: 33cmSize: 81mm x 21mm x 26mm(L*W*H)Ingress Protection Rating: IP65Color: Brass ToneNet Weight: 115g Package Included:1 x Water Flow Sensor

Note

1. Installed in accordance with flow direction in the of product, otherwise there is no signal output.
